Extreme Cool 360 BLUE Thermal Pads

Description

The EC360® BLUE series presents the premium variant of our all-round silicone-based thermal pads with the best price-performance ratio regarding thermal conductivity. It features the highest thermal conductivity for our all-round thermal pads of 5 W/mK.

It is suitable for a variety of applications including GPUs (that are cooled by thermal pads), memory chips and other electrical components. The pads have a rubber like consistency, which means that they will deform under pressure and spring back into their original shape. The slight adhesion of the pads allows for easy positioning.

It is the perfect solution for heat-transfer in adverse surface conditions when the use of thermal paste is unsuitable.

Handling is particularly safe, as the pads are electrically isolating and there is no risk of short-circuiting. Additionally, they can easily be cut using a scissor, which allows trimming pads to the perfect size for any surface.

Specs

Types and Configurations

ThicknessAvailable sizes
0.5 mm / 0.02 inches50x50 mm, 100x100 mm, 200x200 mm
1.0 mm / 0.04 inches50x50 mm, 100x100 mm, 200x200 mm
1.5 mm / 0.06 inches50x50 mm, 100x100 mm, 200x200 mm
2.0 mm / 0.08 inches50x50 mm, 100x100 mm, 200x200 mm
3.0 mm / 0.12 inches50x50 mm, 100x100 mm, 200x200 mm
4.0 mm / 0.16 inches50x50 mm, 100x100 mm, 200x200 mm
5.0 mm / 0.20 inches50x50 mm, 100x100 mm, 200x200 mm

Technical Properties

PropertiesUnitValueTest method
Color-bluevisual
Thermal ConductivityW/mk5.0ASTM D 5470
Specific Gravityg / cm^32.9ASTM D 792
HardnessShore OO30ASTM D 2240
Tensile Strengthpsi2.1ASTM D 412
Elongation%10ASTM D 412
Volume ImpedanceOhm-cm1.0 x 10¹¹ASTM D 257
Breakdown VoltagekV/mm4.0ASTM D 149
Dielectric Constant1Mhz6.0ASTM D 150
Usable Temperatures°C-60 - 200EN 244
Flame Rating-VOUL 94

Gallery

EC360® BLUE 50x50MM

EC360® BLUE 100x100MM

EC360® BLUE 200x200MM
